Villeroy & Boch ViConnect 80 Outlet Valve | For Slim Concealed Cisterns

STOP: Perform the Villeroy & Boch Sticker Test Villeroy & Boch cisterns look identical from the outside. To ensure this “80mm Slim” valve fits, you must check the sticker inside your cistern tank:

• The Brand: Your flush plate must have Villeroy & Boch embossed on it.

• The Depth: This valve is exclusively for the 80mm Slimline cistern (designed for narrow wall cavities).

• The Visual Clue: If your valve has two black actuation cables and the tank feels significantly thinner than a standard brick, this is your part.

• The Alternative: If you have a standard depth or undercounter cistern, you likely need the ViConnect Low-Level Outlet Valve.

On the right hand side, the sticker should say CC 80 FO-2V-2C. It has 2 black cables, and is originally made by Sanit for Villeroy & Boch.

Genuine V&B Factory Spare Part The ViConnect 80 system is a marvel of space-saving engineering, but the specialized narrow dimensions mean only this specific valve will function correctly.

Common Symptoms of Failure:

• Continuous Running: If the toilet won’t seal after flushing and water trickles into the bowl, the base seal or the valve housing has likely perished.

• Non-Activation: If you press the button and nothing happens, the black cables (which come included with this valve) may have malfunctioned or lost tension.

• Stiff Buttons: If the flush feels “heavy,” the internal cable-driven mechanism is likely worn.

Complete Your Repair:

• Won’t Stop Filling? If the water is spilling into the overflow because the tank won’t shut off, you need the ViConnect Universal Inlet Valve. This inlet valve is compatible with both the 80mm Slim and the standard cisterns.

Fastest Dispatch in Sydney

As the leading specialist in Villeroy & Boch spares, we understand the urgency of a broken toilet:

• 8 out of 10 orders are delivered on or before the estimated time.

• Less than 24-hour handling: We dispatch most in-stock orders the same business day.

• In a Hurry? We are located in Mascot, Sydney. Order online and organize your own Uber pickup for immediate collection.

• Q: Do the black cables come with the valve?

  • A: Yes. The cables and the outlet valve are a single integrated unit. Replacing the whole assembly is the only way to ensure the cables are perfectly tensioned for a crisp flush.

• Q: My button doesn’t say Villeroy & Boch, but it looks the same.

  • A: Do not guess. This valve is proprietary to the ViConnect system. If your plate does not say Villeroy & Boch, please contact us with a photo of the internal sticker before ordering.

• Q: Is this easy to install?

  • A: Yes. The ViConnect 80 is designed for “tool-free” maintenance through the flush plate access hole.
